Z20K14x系列

基于ARM CORTEX M4F的中高端微控制器,主频高达160 MHz,高达2M P FLASH + 128K D FLASH, 8路CANFD,6路UART/LIN接口,满足ASIL-B,适用于车身控制、空调控制、照明控制、电子换挡器、安全带预紧、新能源类的各种应用。

zhixin-product

主要特点

  • 基于ARM CORTEX M4F的中高端微控制器
  • 主频高达160 MHz
  • 提供两块物理独立的大容量FLASH(2M P FLASH + 128KB Data FLASH)
  • 8路CANFD
  • 6路UART/LIN接口
  • 满足ASIL-B
zhixin-product

目标应用

  • 适用于车身控制
  • 空调控制
  • 照明控制
  • 电子换挡器
  • 安全带预紧
  • 新能源类的各种应用
zhixin-product

开发工具

  • Z20K14x系列评估板:Z20K148EVB
    • 工作电压:DC12V
    • 1路高速CANFD接口,1路LIN接口
    • 1路电位计模拟输入
    • RGB氛围灯
    • 2个开关按键
    • JTAG/SWD调试接口
    • USB转串口
    • Arduino Shield接口
  • 开发环境
    • IAR Embedded Workbench for Arm | IAR Systems
    • Keil Embedded Development Tools for Arm, Cortex-M
    • GreenHills
  • 调试器
    • JLINK
    • ULINK
    • Lauterbach
  • 烧写器
    • P&E Cyclone Pro
    • 戎象
    • 力捷丰

Software Version Reference

Software Name Version
SDK 1.0
AUTOSAR MCAL 1.2.1
FreeRTOS 1.0
Bootloader(CAN, LIN) 1.5.1
Emulation EEPROM 1.3
ZXPinsConfigurationTool 1.7.1
CodeAutoGeneratorTool 1.2.1
ZXCANBitRateCalculationTool 1.2

Technical Documents Version Reference

Document Version
Product Brief 0.3
Reference Manual 1.2
DataSheet 1.2
Errata Sheet 1.2

TECHNICAL DOCUMENTS QUICK REFERNCE

Document Description
Application Notes Specification of how to use a component in an application or process
Data Sheet Specification of the performance and other characteristics of a component
Release Notes Description of changes and issues in an upcoming update
Package Information Package details of the component
Reference Manual Specification of how to use a component in an application process
Product Brief Essential information to evaluate a product for design suitability quickly
User Guide Procedural manual with step-by-step instructions on how to perform a set of tasks
Supporting Manual A manual or a user guide of a supporting development tool.
